Mechanical Clamps for Rolled Sheet Coils

Mechanical Clamps for Rolled Sheet Coils for lifting, transporting and handling rolled sheet coils.

Dinaksa designs and builds a wide range of coil handling systems for the lamination and paper industries.

The reel holder tongs are an electro-mechanical system for the global movement of metal and paper reels, although this same extension is valid for the movement of cylinders, palletized sheets, etc.

The use of reel holder clamps means the reduction of handling times, thus increasing the productivity of the process and the safety in the movement of heavy loads.

The active safety systems incorporated in the reel holder clamps, among which electro-mechanical and electronic systems, light and acoustic signals, radio, television, etc. stand out.

Different options can be integrated; motorized rotation, integrated weighing system, retractable legs, special protections, etc.

As in all Dinaksa special products, custom modifications are made, as well as the comprehensive project approach together with the customer’s engineering.

CHARACTERISTICS

• PowerSupply : 380 VIII.
• Capacity: Custom.
• Working group: FEM M7 / DIN 4m.
• Opening and closing of arms: Electro-mechanical
• Clamp rotation: Electro-mechanical up to 360º
• Presence sensors: Electro-mechanical
• Opening and closing limit switch sensor: Electro-mechanical
• Opening and closing protection: Electro-mechanical
• Weighing system: Optional
