Load Cell Traction + Compression DKCTR

por Dinaksa - ENG | Sep 13, 2022

Load Cell Traction + Compression DKCTR

CAPACITY:  0.75, 1, 1.5, 2, 3, 5 Ton.

• Cell designed to work with traction forces, with sensor element under cut.
• Equipped with insulating bushings of high mechanical strength.
• Can be used with shackles, standard or specific moorings, for each capacity. Built in smelting.

Load Cell Traction DKGH

por Dinaksa - ENG | Sep 11, 2022

Load Cell Traction DKGH

Technical Data

Sensitivity: 2mV/V
Sensitivity tolerance adjustment: 0.1%
Zero tolerance adjustment: 1% F.E.
Excitation voltage: ≤ 12V
Non- linearity: <0.015% F.E.
non-repeatability: <0.011% F.E.
Error combinado <0.027% F.E.
hysteresis 0.009% F.E.
Fluency in 30 minutes <0.025% F.E.
Temp. effect in sensitivity <0.023% F.E.
Temp. effect at zero <0.016%/5ºC
Compensated temperature range -10ºC/+40ºC
input resistance 380Ω±10Ω
output resistance 350Ω±3Ω
isolation resistance (V.Test=100V) >5000 10⁵Ω
peak workload 150% F.E.
Load limit without losing features 200% F.E.
breaking load >300% F.E.
flexible cable 4×0.25mm
Protection IP 66
Anti-corrosion treatment of chemical nickel.
